For commercial applications, the Plasma Air 7000 provides safe and continuous air purification using patented soft ionization, also known as bipolar ionization. The number of units and the quantity of the ionization outlets are dependent on the airflow in the system and the severity of the indoor air pollution problem.
The Plasma Air 7000 Series Models 7100 / 7200 / 7300 / 7400 needlepoint ionizers are rated up to 6,000 CFM and produce positively and negatively charged ions that reduce and neutralize harmful pathogens, pollutants, and odors. They are typically installed in supply ducts utilizing the pre-drilled flange and factory-applied gaskets. They can also be installed inside an HVAC unit utilizing a contractor-supplied mounting bracket
| Airflow Capacity (71XX): | Up to 1,400 CFM |
| Airflow Capacity (72XX): | 1,401 to 2,800 CFM |
| Airflow Capacity (73XX): | 2,801 to 4,200 CFM |
| Airflow Capacity (74XX): | 4,201 to 6,000 CFM |
| Compliance: | UL2998, Intertek/ETL Standard UL 867, UL 867, CSA C22.2# 187, UL 2998, UL 2043, CARB, ISO 16000 |
| Power Consumption: | Less than 2VA per set of outputs |
| Weight: | 2.0 lb |
| Voltage Input (7XX1): | 24V AC |
| Voltage Input (7XX2): | 120V AC wall pack |
| Voltage Input (7XX3): | 120V/240V AC power supply |
| Voltage Input (7XX4): | 277V AC – 12V DC power supply |
| Mode of Operation: | Recessed, Needlepoint Type |
| BAS Monitoring: | Dry contact terminals |
| Dimensions: | 6.5″ × 6.5″ × 3.5″ |
